Graham Field Automatic Wrist Blood Pressure Monitor

Authorized Retailer Badge


 WARNING: Cancer and Reproductive Harm -



Item# Description Pkg reward$ Price Blank
Item #: 1143
Automatic Wrist Blood Pressure Monitor

Graham Field Automatic Wrist Blood Pressure Monitor is intended for the noninvasive measurement of systolic and diastolic arterial blood pressure and pulse rate in adults (age 15 and above). The sensor of the device catches weak fluctuation of the pressure in the wrist cuff produced by extension and contraction of the artery of the wrist in response to each heartbeat. The amplitude of the pressure waves is measured, converted in millimeters of the mercury column, and is displayed by digital value. Consult your physician before using this device on children or persons with arrhythmia.

Graham Field Wrist Blood Pressure Monitor Highlights

  • Device uses oscillometric technology
  • Wrist cuff is inflated by an air pump.

Graham Field Wrist Blood Pressure Monitor Features

  • Automatic Inflation and Deflation Wrist Blood Pressure and Pulse Monitor
  • Memory feature one (1) user with 90 memory readings (improved from 85 readings)
  • Average value for the latest 3 readings (new feature)
  • Fast reading in seconds
  • WHO blood pressure classification indication (new feature)
  • Date / Time display in 12 hour format
  • Includes: storage case & 2 AAA batteries

Graham Field Automatic Wrist Blood Pressure Monitor User Manual

More About Graham Field Wrist Blood Pressure Monitor


It is necessary to know that arterial blood pressure is subjected to sharp fluctuations. The level of the arterial blood pressure depends on many factors. Generally arterial blood pressure is lower in the summer and higher in the winter. Arterial blood pressure changes with atmosphere pressure and is affected considerably by many factors, e.g. physical loads, emotional excitability, stress, meals, etc. Medicines, drinking, and smoking can affect blood pressure. When blood pressure is measured in the hospital, the value is sometimes higher than when taken at home. This is believed to be associated with anxiety experienced during the hospital/clinic visit. Blood pressure may be elevated when taken in low temperatures. If this device was stored at a low temperature, it is necessary to leave it at room temperature for at least 1 hour, otherwise the measurement can be inaccurate. Blood pressure varies by age and from person to person, and it is recommended to record blood pressure daily; then you can check with your physician to find out what normal blood pressure is for you.

2. Patients with cardiovascular diseases: Take measurement under doctors instruction.

3. Accurate measurement of blood pressure may be difficult in people with serious arteriosclerosis, weak pulse, or in patients with irregular heart rates. Please consult a qualified physician to interpret your blood pressure readings.

4. Keep quiet and relax during measurement. To obtain accurate readings, wait one hour after a meal or smoking before taking a measurement.

5. Wait at least 5 minutes before taking the next measurement. Atherosclerosis and diabetes patients require longer intervals (10-15 minutes), since vessel elasticity may have decreased in these pathologies.


Sit down and place your elbow on a table. Ensure the wrist is at approximately the same level as the heart, and the forearm is extended naturally, palm up. Wrap the cuff around the left wrist as shown in the illustration, and ensure the cuff is attached to the wrist securely with the display facing the user. Loosen and roll up sleeves so that the blood pressure monitor wrist cuff is in direct contact with the wrist during measurement.


It is necessary to protect this device against high moisture, direct sunlight, shock, alcohol and gasoline.

2. Remove the batteries if the device is to be stored for a long period of time, and keep the batteries away from children.

3. Prevent sharp objects from coming into contact with the wrist cuff, and do not stretch or twist the wrist cuff.

4. Use only clean, soft, dry cloths to clean the device.

5. The wrist cuff is sensitive and must be handled with care. Clean the wrist cuff cover with a clean, damp cloth. Ensure the cuff is dry before taking a new measurement.

6. Since neither this device nor batteries are household waste, follow your local recycling rules and dispose of them at appropriate collection sites.

Warning WARNING: Cancer and Reproductive Harm -
